Controls1:Gain, Tone, Level
Current Draw:30.4 mA
Dimensions:5.04"in x 3.45"in x 2.50"in (128.0 mm x 87.6 mm x 63.5 mm)
Input Impedance:1 Megohm
Led Indicators:Red, yellow, and blue bugles in the Maestro logo illuminate when the pedal is active
Output Impedance:1 kOhms
Power On Switch:Incorporated into the input jack. Unplug the input when not in use to prevent battery drain. Remove the battery when the pedal is going to be stored for long periods to prevent leakage and damage.
Power Requirements:9V battery or regulated 9-12*VDC power supply (5.5 x 2.1 mm plug, wired center-negative) *Running the pedal at 12V provides increased headroom
Signal Processing:All-Analog
Switches:True Bypass footswitch, Hi/Lo Mode toggle switch
Switching Type:True Bypass
Weight:Net: 1.23 lb. (557.9 gm.) Gross: 1.61 lb. (730.3 gm.)
Model:MOCROP
