| Active or Passive |
Active |
| System Type |
Full-Range |
| Configuration |
2-way |
| System Continuous Power |
320 W |
| System Peak Power |
640 W |
| Max SPL @ 1m |
125 dB |
| Freq Response (+/-3 dB) |
63 Hz - 20 kHz |
| Freq Range (-10 dB) |
55 Hz - 20 kHz |
| Bluetooth |
Yes |
| IP Certification |
None |
| Driver Brand |
Wharfedale Pro |
| LF Driver Size |
10" |
| LF Voice Coil Size |
2.5" |
| LF Rated Impedance |
4 Ω |
| LF Power (RE:AES2-2012) |
280 W |
| HF Driver Type |
Compression Driver |
| HF Voice Coil Size |
1.33" |
| HF Diaphragm Material |
Titanium |
| HF Exit Size |
1.37" |
| HF Power (RE:AES2-2012) |
40 W |
| HF Rated Impedance |
8 Ω |
| Preset Library |
No |
| Input Connector |
2 x 1/4” Jack / XLR Combo |
| Waveguide Type |
Constant Directivity |
| Enclosure Material |
Polypropylene |
| Grille Material and Finish |
Steel Black |
| Finish |
Black Polypropylene |
| Handles |
2 |
| Deployment |
Ground, Flying, Pole, Wall Mount |
| Pole Mount |
Dual Angle (0° / -3°) 35 mm |
| Brackets Included |
No |
| Rigging |
Yes |
| M8 |
5 |
| Nominal Coverage (H x V) |
90° x 60° |
| Sensitivity 2.83v / 1m |
n/a dB |
| System Rated Impedance |
n/a |
| Crossover Frequency |
2.0 kHz |
| Amplifier design |
Class D |
| DSP Controls |
Normal / Live / DJ / Speech |
| Preset list |
Normal / Live / DJ / Speech |
| Active loudspeaker Input Impedance |
10 KΩ Balanced |
| Link Connector |
pin XLR |
| Input sensitivity |
+4 dBu |
| Max input level |
+18 dBu |
| Line output |
Pin XLR |
| 240 V AC W (1/8 rated output power) |
99 |
| 120 V AC W (1/8 rated output power) |
99 |
| Idle W |
20 |
| Main Power |
100-120 V~/220-240 V~,50/60 Hz |
| Power Supply |
SMPS |
| Unpacked - Height (mm) |
528 |
| Unpacked - Width Front (mm) |
320 |
| Unpacked - Width Rear (mm) |
179 |
| Unpacked - Depth (mm) |
300 |
| Packed - Height (mm) |
582 |
| Packed - Width Front (mm) |
367 |
| Packed - Width Rear (mm) |
367 |
| Packed - Depth (mm) |
342 |
| Weight - Nett (kg) |
12.6 |
| Weight - Gross (kg) |
13.7 |
