| Inputs |
2 |
| Outputs |
6 |
| Input Type |
Analog |
| Input Connections |
XLR |
| Output Connections |
XLR |
| Input Impedance |
Balanced : 20 KΩ |
| Output Impedance |
Balanced : 100 KΩ |
| Input Effects |
Gain, Mute, Link, High-pass filter, Low-pass filter, Noise Gate, 8-band parametric EQ, 31 band graphic EQ, Phase, Delay |
| Output Effects |
Crossover, 5-band parametric EQ, Gain, Mute, Compressor / Limiter, Phase, Delay , Linking |
| Input Range |
≤ +16.3 dBu |
| Frequency Response |
19.7 Hz – 20 KHz (+/- 0.5 dB) |
| PC Port |
Yes |
| CMRR |
>70 dB (1 KHz) |
| SNR |
>104 dB |
| THD+N |
< 0.01% (Output = 0 dBu / 1 KHz) |
| Channel Separation |
> 100 dB (1 KHz) |
| Processor |
32-bit |
| AD/DA Converter |
24-bit, 96 KHz |
| Software Included |
Yes |
| Ethernet |
Yes |
| Impedance |
Balanced : 100 KΩ |
| Display Type |
2 x 24 LCD backlight display. 5-band LED display. Mute / Editing status |
| Password Protected |
Yes |
| Main Power |
AC 110 V / 220 V 50 / 60 Hz |
| Included Accessory |
Power Cable, User Manual |
| Unpacked - Height (mm) |
44 |
| Unpacked - Width Front (mm) |
482 |
| Unpacked - Width Rear (mm) |
482 |
| Unpacked - Depth (mm) |
190 |
| Packed - Height (mm) |
98 |
| Packed - Width Front (mm) |
562 |
| Packed - Width Rear (mm) |
562 |
| Packed - Depth (mm) |
296 |
| Weight - Nett (kg) |
3.6 |
| Weight - Gross (kg) |
4.5 |
