SOUND GENERATOR
Piano Sound – Piano Reality Modeling Premium Sound Engine
Max. Polyphony – Piano: Limitless (solo playing using ‘Piano’ category tones) Other: 256
Tones
– Total 324 Tones
– Grand: 4 Tones
– Upright: 5 Tones
– Classical: 5 Tones
– E.Piano: 12 Tones
– Organ: 12 Tones
– Other: 286 Tones
AMBIENCE
Ambience
– Piano Reality Ambience
– Type: Studio, Lounge, Concert Hall, Cathedral
– Depth: 11 types
KEYBOARD
Keyboard – Piano Reality Hybrid Premium Keyboard (88keys Hammer Action Keyboard): with Escapement, Ebony/Ivory Feel and Dynamic Sensor Acceleration Technology
PEDAL
Pedal
– Damper (Piano Reality Premium Pedal, capable of continuous detection, Damper Modeling)
– Soft (capable of continuous detection, function assignable)
– Sostenuto (function assignable)
SOUND SYSTEM
Sound System – Piano Reality Projection Premium Sound System
Speakers
– Spatial Speakers: 12 cm (4-3/4 inches) x 2
– Cabinet Speakers: 20 cm (7-7/8 inches) (with Speaker Box)
– Near-field Speakers: 5 cm (2 inches) x 2
Rated Power Output
– 25 W x 2
– 20 W x 1
– 15 W x 2
HEADPHONES
Headphones – Piano Reality Headphones Ambience
CABINET
Cabinet
– Piano Reality Cabinet Design
– Music rest: with Music holders
– Key cover: Slide type, with Keyboard Lid Switch
TUNING, VOICING
Touch Sensitivity
– Key Touch: 100 types, fixed touch
– Hammer Response: Off, 10 types
Master Tuning
– 415.3–466.2 Hz (adjustable in increments of 0.1 Hz)
Temperament – 10 types (Equal, Just Major, Just Minor, Pythagorean, Kirnberger I, Kirnberger II, Kirnberger III, Meantone, Werckmeister, Arabic), selectable temperament key
Effects – Brilliance
Piano Designer
– Lid
– Key Off Noise
– Hammer Noise
– Duplex Scale
– Full Scale String Resonance
– Damper Resonance
– Key Off Resonance
– Cabinet Resonance
– Soundboard Type
– Damper Modeling
– Single Note Tuning
– Single Note Volume
– Single Note Character
INTERNAL SONGS
Internal Songs
– Total 394 songs
– Listening: 27 songs
– Ensemble: 30 songs
– Entertainment: 20 songs
– Let’s Sing with DO RE MI: 30 songs
– Lesson: 287 songs (Scale, Hanon, Beyer, Burgmuller, Czerny 100)
DATA PLAYBACK
Playable Software
– Standard MIDI Files (Format 0, 1)
– Audio File (WAV: 44.1 kHz, 16-bit linear format, MP3: 44.1 kHz, 64 kbps – 320 kbps, requires USB flash drive)
RECORDER
Recordable Software
– Standard MIDI Files (Format 0, 3 parts, Approx. 70,000 notes memory)
– Audio File (WAV: 44.1 kHz, 16-bit linear format, requires USB Flash Memory)
BLUETOOTH
Bluetooth
– Bluetooth Ver 4.2
– Profile: A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)
– CODEC: SBC (Supports SCMS-T content protection)
COMPATIBLE ANDROID / IOS APPS (ROLAND)
Compatible Android / iOS Apps (Roland) – Roland Piano App, Piano Designer
CONVENIENT FUNCTIONS
Convenient Functions
– Metronome (adjustable Tempo/Beat/Down beat/Pattern/Volume/Tone, with Rhythm Pattern: 80 pattern)
– Dual
– Split
– TwinPiano (with Individual Mode)
– Transpose (in semitones)
– Speaker volume and Headphones volume automatically select function
– Speaker Auto Mute
– Volume limit function
– Panel Lock
– Panel Sleep
– Auto Off
OTHER
Display – Graphic LCD 128 x 64 dots
Connectors
– DC In jack
– Input jacks: Stereo miniature phone type
– Output (L/Mono, R) jacks: 1/4-inch phone type
– USB Computer port: USB B type (compatible with USB MIDI/Audio)
– USB Memory port: USB A type
– Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone type
Power Supply – AC adaptor
Power Consumption
– Power Consumption: 31 W (when using the included AC adaptor)
* Approximate power consumption when playing the piano at medium volume: 17 W
* Power consumption when sound has not been played after power-on: 16 W
Accessories
– Owner’s Manual
– “Roland Piano Masterpieces”
– Leaflet “Leaflet Stand Assembly”
– Leaflet “USING THE UNIT SAFELY”
– Power cord
– Headphone hook
Option (sold separately) – Headphones
SIZE AND WEIGHT
Width
Top opened (with music rest):
1,412 mm
55-5/8 inches
Top closed (with music rest):
1,404 mm
55-5/16 inches
Depth
Top opened (with music rest):
959 mm
37-13/16 inches
Top closed (with music rest):
959 mm
37-13/16 inches
Height
Top opened (with music rest):
1,526 mm
60-1/8 inches
Top closed (with music rest):
931 mm
36-11/16 inches
Weight
91.0 kg/200 lbs 10 oz
