| | | Width |
1,430 mm [56-5/16"] |
|
|---|
| Height |
932 mm [36-11/16"] (with music rest raised: 1,094 mm [43-1/16"]) |
|
|---|
| Depth |
1,237 mm [48-11/16"] |
|
|---|
| | Weight |
135 kg [297 lb, 10 oz] |
|
|---|
| | W x H x D |
1,570 mm x 620 mm x 1,410 mm [61-13/16" x 24-7/16" x 55-1/2"] |
|
|---|
| | | Number of Keys |
88 |
|
|---|
| Type |
GrandTouch™ keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement |
|
|---|
| Touch Sensitivity |
Hard2, Hard1, Medium, Soft1, Soft2, Fixed |
|
|---|
| 88-key Linear Graded Hammers |
Yes |
|
|---|
| Counterweight |
Yes |
|
|---|
| | Number of Pedals |
3: Damper (with half-pedal function), Sostenuto, Soft |
|
|---|
| GrandTouch Pedals |
Yes (with GP Response Damper) |
|
|---|
| Assignable Functions |
Sustain (Switch), Sustain (Continuous), Sostenuto, Soft, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause |
|
|---|
| | Type |
Full Dots LCD |
|
|---|
| Language |
English, Japanese |
|
|---|
| | Type |
Touch sensors |
|
|---|
| Language |
English |
|
|---|
| | Key Cover Style |
Sliding |
|
|---|
| Music Rest |
Yes |
|
|---|
| Music Braces |
Yes |
|
|---|
| | | Piano Sound |
Yamaha CFX, Bösendorfer Imperial |
|
|---|
| Binaural Sampling |
Yes (“CFX Grand” and “Bösendorfer” only) |
|
|---|
| Virtual Resonance Modeling (VRM) |
Yes |
|
|---|
| Grand Expression Modeling |
Yes |
|
|---|
| | Number of Polyphony (Max.) |
256 |
|
|---|
| | Number of Voices |
53 Voices + 480 XG Voices + 14 Drum/SFX Kits |
|
|---|
| Compatibility |
XG (GM), GS (for Song playback), GM2 (for Song playback) |
|
|---|
| | | Reverb |
7 types |
|
|---|
| Chorus |
3 types |
|
|---|
| Brilliance |
7 types + User |
|
|---|
| Insertion Effect |
12 types |
|
|---|
| Intelligent Acoustic Control (IAC) |
Yes |
|
|---|
| Stereophonic Optimizer |
Yes |
|
|---|
| | Dual/Layers |
Yes |
|
|---|
| Split |
Yes |
|
|---|
| Duo |
Yes |
|
|---|
| | | Number of Preset Songs |
27 Voice Demo + 50 Classics + 303 Lesson Songs |
|
|---|
| | Number of Songs |
250 |
|
|---|
| Number of Tracks |
16 |
|
|---|
| Data Capacity |
Approx. 500 KB/Song (approx. 22,000 notes) |
|
|---|
| | Recording Time (max.) |
80 minutes/Song |
|
|---|
| | Playback |
SMF (Format 0, Format 1), WAV (44.1 kHz, 16-bit, stereo) |
|
|---|
| Recording |
SMF (Format 0), WAV (44.1 kHz, 16-bit, stereo) |
|
|---|
| | Piano Room |
Yes |
|
|---|
| | Number of Rhythms |
20 |
|
|---|
| | Metronome |
Yes |
|
|---|
| Tempo Range |
5 – 500 |
|
|---|
| Transpose |
−12 – 0 – +12 |
|
|---|
| Tuning |
414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments) |
|
|---|
| Scale Type |
7 types |
|
|---|
| USB Audio Interface |
44.1 kHz, 24 bit, stereo |
|
|---|
| Bluetooth |
Audio, MIDI (varies by area) |
|
|---|
| | | Internal Memory |
Total maximum size approx. 1.4 MB |
|
|---|
| External Drives |
USB flash drive |
|
|---|
| | Headphones |
Standard stereo phone jack (× 2) |
|
|---|
| AUX IN |
Stereo mini jack |
|
|---|
| AUX OUT |
Standard phone jack (L/L+R, R) |
|
|---|
| USB TO DEVICE |
Type A |
|
|---|
| USB TO HOST |
Type B |
|
|---|
| DC IN |
24 V |
|
|---|
| | Amplifiers |
(45 W + 45 W + 45 W) × 2 |
|
|---|
| Speakers |
(16 cm + 8 cm with Waveguide + 2.5 cm (dome) with Waveguide) × 2, Spruce Cone Speaker |
|
|---|
| | AC Adaptor |
PA-500 |
|
|---|
| Power Consumption |
60 W (When using PA-500 AC adaptor) |
|
|---|
| Auto Power Off |
Yes |
|
|---|
| | Included Accessories |
Owner’s Manual, “50 Classical Music Masterpieces” Music Book, Online Member Product Registration, Bench*, Power cord*/AC adaptor* (PA-500) *Varies by area |
|
|---|
| Separately Sold Accessories |
Headphones (HPH-150, HPH-100, HPH-50), Pedal unit (FC35), AC adaptor (PA-500), USB wireless LAN adaptor (UD-WL01) |
|
|---|
